Radiation cannot only be absorbed by a sample but it also can be scattered by a sample. The scattering process is usually a result of interaction with particles, such as colloidal suspensions (i.e.Tyndale-Scattering) or by large molecules or small particles (i.e. Rayleigh Scattering). The wavelength ((λ) of the scattered light is mostly unchanged from that of the incident light. The intensity of the scattered light (Is) is given by the following equation,
Is = k.λ-4
It follows the intensity of the scattered light is strongly dependent on the incident light wavelength.
An example of the scattering of shorter wavelength light is the blue colour of the sky. The blue light is preferentially scattered by very small particles contained in the atmosphere. Under some circumstances the transmitted (unscattered light) is observed as red due to the removal of the blue light (e.g. in the sunset). An optical arrangement that can measure scattered light and identify its wavelength is shown in figure 4. Light from a laser beam is focussed through the sample cell onto a plane mirror that reflects back the light to double the scattering process. The scattered light is collected by a similar lens-mirror combination that focuses it onto the dispersing unit of a spectrometer.
About the Author
RAYMOND PETER WILLIAM SCOTT was born on June 20 1924 in Erith, Kent, UK. He studied at the University of London, obtaining his B.Sc. degree in 1946 and his D.Sc. degree in 1960. After spending more than a decade at Benzole Producers, Ltd. Where he became head of the Physical Chemistry Laboratory, he moved to Unilever Research Laboratories as Manager of their Physical Chemistry department. In 1969 he became Director of Physical Chemistry at Hoffmann-La Roche, Nutley, NJ, U.S.A. and subsequently accepted the position of Director of the Applied Research Department at the Perkin-Elmer Corporation, Norwalk, CT, U.S.A.
In 1986 he became an independent consultant and was appointed Visiting Professor at Georgetown
University, Washington, DC, U.S.A. and at Berkbeck College of the University of London; in 1986 he retired but continues to write technical books dealing with various aspects of physical chemistry and physical chemical techniques. Dr. Scott has authored or co-authored over 200 peer reviewed scientific papers and authored, co-authored or edited over thirty books on various aspects of physical and analytical chemistry. Dr. Scott was a founding member of the British chromatography Society and received the American Chemical society Award in chromatography (1977), the M. S. Tswett chromatography Medal (1978), the Tswett chromatography Medal U.S.S.R., (1979), the A. J. P. Martin chromatography Award (1982) and the Royal Society of Chemistry Award in Analysis and Instrumentation (1988).
Dr. Scott’s activities in gas chromatography started at the inception of the technique, inventing the Heat of Combustion Detector (the precursor of the Flame Ionization Detector), pioneered work on high sensitivity detectors, high efficiency columns and presented fundamental treatments of the relationship between the theory and practice of the technique. He established the viability of the moving bed continuous preparative gas chromatography, examined both theoretically and experimentally those factors that controlled dispersion in packed beds and helped establish the gas chromatograph as a process monitoring instrument. Dr. Scott took and active part in the renaissance of liquid chromatography, was involved in the development of high performance liquid chromatography and invented the wire transport detector. He invented the liquid chromatography mass spectrometry transport interface, introduced micro-bore liquid chromatography columns and used them to provide columns of 750,000 theoretical plates and liquid chromatography separations in less than a second. Dr. Scott has always been a “hands-on” scientist with a remarkable record of accomplishments in chromatography ranging from hardware design to the development of fundamental theory. He has never shied away from questioning “conventional wisdom” and his original approach to problems has often produced significant breakthroughs.
